steering motor driver
This industrial-grade brushless motor driver operates at 48V, 250W, and 15A, and is designed to control rotary motors with stepless speed regulation. It offers a range of intelligent protection features and optimized performance for reliable and safe operation.
Key Features:
- Silent Operation: Effectively reduces noise and vibration during startup by addressing the pulsating current characteristics of brushless motors.
- Soft and Safe Start: Ensures a smooth and secure motor start while increasing initial torque.
- Speed-Limited Forward/Reverse Function: Limits speed during reverse operation for added safety.
- Undervoltage Protection: Automatically stops output when battery voltage drops below the preset threshold to prevent battery over-discharge and damage.
- Overcurrent Protection: Cuts off output if current exceeds set limits, protecting the motor and battery from high current surges.
- Stall Protection: Limits current during a stall and cuts power after 3 seconds to prevent motor and controller burnout.
- MOSFET Short-Circuit Detection: Automatically detects MOSFET shorts at power-on to prevent cascading failures.
- Overtemperature Protection: Reduces output current when the controller temperature exceeds safe limits, protecting internal components.
This motor driver is ideal for precision control in the steering system of remote-controlled forklifts.
